NIEDERBERGER NCS-P6/3-ST
Categories
Brush Deburring Machine
Object
50672
Brand
NIEDERBERGER
Model
NCS-P6/3-ST
YoM
2007
Controls
SIEMENS S7 300
Object
50672
| specifications through feed grinding machine | ||
|---|---|---|
| Working width: | 330 | mm |
| number of brushing station: | 3 | |
| demagnetizer: yes | ||
| transportation belt | ||
|---|---|---|
| speed min.: | 1.4 | m/min |
| speed max.: | 14 | m/min |
| demagnetizer: yes | ||
| coolant unit: yes | ||
| Electrical specifications | ||
|---|---|---|
| total power consumption: | 7 | kW |
| Dimensions / weights | ||
|---|---|---|
| space requirements -left/right-: | 4510 | mm |
| space requirements -front/back-: | 1806 | mm |
| total height: | 2320 | mm |
| total weight approx.: | 5500 | kg |
| Equipment: 3 brushing units: each with 5 satellites (3.2 kW per unit) -Head rotation: 80-200 rpm -Brush rotation: 800-3000 rpm 1 spray and blow-off system 1 conveyor belt: both belt and sanding belt possible 4 magnetic plates Special feature: Demagnetization and blow-off station at the belt outlet |
| Equipment: 3 brushing units: each with 5 satellites (3.2 kW per unit) -Head rotation: 80-200 rpm -Brush rotation: 800-3000 rpm 1 spray and blow-off system 1 conveyor belt: both belt and sanding belt possible 4 magnetic plates Special feature: Demagnetization and blow-off station at the belt outlet |
