NAKAMURA SUPER NTM³
Categories
Turning and Milling Center
Object
56583
Brand
NAKAMURA
Model
SUPER NTM³
YoM
2007
Controls
FANUC 31I MODEL A
Object
56583
| basic functions | ||
|---|---|---|
| number of spindles: | 2 | |
| number of turrets: | 3 | |
| live positions: yes | ||
| number of c-axes: | 3 | |
| number of y-axes: | 3 | |
| Working Range Turning | ||
|---|---|---|
| turning diameter (max): | 170 | mm |
| bar diameter (max): | 45 | mm |
| worpiece length max.: | 588 | mm |
| main spindle | ||
|---|---|---|
| spindle revolutions (max): | 6000 | /min |
| spindle bore diameter: | 42 | mm |
| spindle positioning: | 0.001 | ° |
| c-axis: yes | ||
| counter spindle | ||
|---|---|---|
| spindle revolutions (max): | 6000 | /min |
| spindle positioning: | 0.001 | ° |
| c-axis: yes | ||
| Electrical specifications | ||
|---|---|---|
| mains voltage: | 400 | V |
| mains frequency: | 50 | Hz |
| Dimensions / weights | ||
|---|---|---|
| space requirements -left/right-: | 3400 | mm |
| space requirements -front/back-: | 2000 | mm |
| total height: | 1900 | mm |
| total weight approx.: | 8000 | kg |
