SHW UNISPEED 5T
Categories
Machining Center - Horiz. (APC)
Object
52106
Brand
SHW
Model
UNISPEED 5T
YoM
2012
Controls
SIEMENS 840 D
Object
52106
Working Range -cubic- | ||
---|---|---|
number of processing axes (excl parallel axes): | 5 | |
X-axis travel: | 2000 | mm |
Y-axis travel: | 1300 | mm |
Z-axis travel: | 1300 | mm |
Table | ||
---|---|---|
clamping surface diameter: | 1600 | mm |
workpiece load (max): | 6000 | kg |
spindle / head | ||
---|---|---|
spindle revolutions (min): | 22 | /min |
spindle revolutions (max): | 6000 | /min |
Axis drives | ||
---|---|---|
traverse velocity X (min): | 30000 | mm/min |
traverse velocity Y (min): | 30000 | mm/min |
traverse velocity Z (max): | 30000 | mm/min |
Tool magazine | ||
---|---|---|
magazin type: chain magazine | ||
number of positions: | 100 |
Electrical specifications | ||
---|---|---|
mains voltage: | 400 | V |
mains frequency: | 50 | Hz |
Dimensions / weights | ||
---|---|---|
space requirements -left/right-: | 6200 | mm |
space requirements -front/back-: | 7400 | mm |
total height: | 4200 | mm |
