SUTHERLAND SD.3600
Categories
Press -hydraulical-
Object
56468
Brand
SUTHERLAND
Model
SD.3600
YoM
2001
Object
56468
| Press forces | ||
|---|---|---|
| total force (nominal): | 600 | to |
| Press Table | ||
|---|---|---|
| table surface (left-right): | 3070 | mm |
| table surface (front-back): | 1530 | mm |
| Slide | ||
|---|---|---|
| stroke: | 305 | mm |
| slide (hydr. Press) | ||
|---|---|---|
| approximation velocity max.: | 296 | mm/s |
| return velocity max.: | 380 | mm/s |
| Tool Assembly Dimensions | ||
|---|---|---|
| passline opening (free passage in side columns): | 1220 | mm |
| Dimensions / weights | ||
|---|---|---|
| space requirements -left/right-: | 4250 | mm |
| space requirements -front/back-: | 2100 | mm |
| total height: | 5700 | mm |
