BEUTLER NOVA CFL 63 C
Kategorije
Avtomat za štancanje
Objekt
49291
Proizvajalec
BEUTLER NOVA
Model
CFL 63 C
Leto
2022
Upravljanje
BECKHOFF CX2033
Objekt
49291
| Press Design | ||
|---|---|---|
| drive system: eccentric / crank | ||
| frame design: C-frame, double sided | ||
| number of slide actions: | 1 | |
| opening in table: yes | ||
| Press forces | ||
|---|---|---|
| total force (nominal): | 63 | to |
| Press Table | ||
|---|---|---|
| table surface (left-right): | 820 | mm |
| table surface (front-back): | 590 | mm |
| thickness of bolster plate: | 75 | mm |
| opening in bed (diameter): | 165 | mm |
| Slide | ||
|---|---|---|
| table surface (left-right): | 470 | mm |
| table surface (front-back): | 415 | mm |
| spigot hole diameter: | 50 | mm |
| slide (mechan. Press) | ||
|---|---|---|
| slide adjustment: | 100 | mm |
| stroke adjustment: yes | ||
| stroke min.: | 8 | mm |
| stroke max.: | 120 | mm |
| stroke rate (min.): | 30 | /min |
| stroke rate (max.): | 120 | /min |
| Tool Assembly Dimensions | ||
|---|---|---|
| shut height (stroke down, adjustment up), BDC: | 320 | mm |
| throat (C-frame): | 280 | mm |
| Electrical specifications | ||
|---|---|---|
| total power consumption: | 4 | kW |
| Dimensions / weights | ||
|---|---|---|
| space requirements -left/right-: | 1310 | mm |
| space requirements -front/back-: | 1660 | mm |
| total height: | 3070 | mm |
| total weight approx.: | 5000 | kg |
| Attachments (presses) | ||
|---|---|---|
| safety guard / safety door: yes | ||
| light barrier: yes | ||
| 2-hand engagement: yes | ||
| foot engagement: yes | ||
| acc. to actual accident protection regulation: yes | ||
| European CE standards: yes | ||
